Canon 20x HD L-Series zoom lens

HD image quality starts with the optics, and the XHA1S delivers the many benefits of Canon's world-renowned lens technologies. The Genuine Canon 20x HD video zoom lens is a professional L-Series lens, incorporating Fluorite and Ultra-Low-Dispersion elements. This state-of-the-art design ensures outstanding resolution, contrast, and color reproduction, delivering image quality throughout the entire zoom range unmatched by conventional optics. The 20x zoom covers an exceptionally wide and useful range of focal lengths, from 32.6 - 650mm (35mm photography equivalent). Canon's Optical Image Stabilization (OIS) uses a gyro sensor to detect camera movement and activate the Lens Shift System to continuously compensate for shake and jitter. the 20x HD video zoom lens on the XHA1S incorporates Canon's Super-Range IS Technology, which further improves low-frequency vibration control by using two detection methods (gyro and vector). The image at the CCD sensor is analyzed, providing additional feedback to the lens shift element for even greater compensation and precision. The result is highly reliable camera shake correction, even at long focal lengths, without any image degradation. The Focus, Zoom, and Manual Iris rings provide the "feel" of a professional broadcast lens. It allows fine, smooth adjustment in 1/8th-stop increments manually. The XHA1S provides superb response, enabling zoom speed control by varying the angle of rotation of the zoom ring with a High-Speed Zoom Mode. Zoom speed can be variable or constant with 16 possible speed level settings, all accessible by using the lens barrel ring, the control on the camera's grip, or the control on the camera's handle. Zoom control is not only more accessible, but much smoother than ever before. Programmable lens presets enable repetitive focus and zoom actions to be memorized for instant recall.

3CCD system and DIGIC DV II HD image sensor

A sophisticated 3CCD design employs separate native 16:9 sensors for each primary color. With 1.67 million pixels (1440 x 1080) per sensor, the effective pixel count of the XHA1S is significantly higher than that of comparable HD camcorders. Canon's superior design thus delivers outstanding picture quality at 1080 HD resolution. It further ensures highly accurate color with wide dynamic range and virtually no color noise. Engineered and manufactured by Canon, the DIGIC Digital Signal Processing Chip (DSP) uses proprietary algorithms and architecture to deliver the highest image quality at the highest operating speeds. The latest-generation DIGIC DV II HD Processor is designed for HD video, operating at 1440 x 1080 pixels with 4:2:2 color sampling. A new hybrid noise reduction system uses dual processes to improve image clarity in monotone and shadow areas. Color reproduction has also been improved, especially in skin tone areas and with dark and light scenes. The DSP also enables high-quality still image recording in either video or digital camera color spaces.

True HD 1080 capture

The XHA1S captures true 1080 High-Definition video, providing images of stunning clarity. Moreover, the frame rate is selectable: capture and output video in 60i, 30F, or 24F as needed to deliver spectacular clarity or evoke the look and feel of film and episodic TV. A 50i/25F option is available, requiring modification at a Canon Service Center. Modified cameras offer the option of switching to 50i or 60i capture in HD mode and PAL or NTSC compatibility in SD modes. You might be happy to know that the XHA1 includes 4:3 output capability, which is highly useful in field situations where a widescreen monitor is not available for viewing 16:9 footage. The "letterboxed" 16:9 image output enables the entire frame to be viewed on a standard-definition 4:3 set.

Instant AF and built-in ND filters

Instant AF is Canon's next-generation autofocus technology. A new external sensor works in combination with Canon's proven high-performance internal AF system to dramatically reduce focusing time and increasing accuracy, even in log-light or high brightness situations. Focusing performance is also much improved with difficult subjects. The high resolution of HD video makes focus more critical than ever, and Canon's Instant AF helps videographers capture HD images with expert precision. Another handy feature on the XHA1S is built-in Neutral Density (ND) filters. Two built in ND filters (1/6 and 1/32) reduce exposure by two or five stops for added image control. They can be used, for example, when shooting bright, sunlit exteriors or to decrease depth of field for a more dramatic, cinematic look. A focus distance readout in the viewfinder assists in setting manual focus.

Connectivity and audio recording

The XHA1S includes a full complement of input and output ports to meet just about any interface requirement. Two XLR mic/line autio inputs accommodate professional balanced connections. Also provided are industry standard connectors, including component (HD/SD) and composite video outputs (BNC/RCA), and IEEE 1394 (Firewire) port, a LANC terminal, and a headphone jack. Individual audio level controls, switchable 20 dB mic attenuation, 12 dB mic gain boost, and various monitoring options provide full control over the sound as it is recorded. They even include switchable phantom power (+48V) to eliminate the need for any external power supply with direct mic input. An external microphone holder is provided for on-camera mounting and for an optional professional shotgun microphone.

High resolution widescreen EVF and LCD

With both an EVF and an LCD, the XHA1S provides a choice of precise, informative displays for image composition and data readout. The 0.57" widescreen EVF is approximately 269,000 pixels. The separate 2.8" widescreen LCD also provides a clear, high-resolution image with approximately 207,000 pixels. You can choose from 22 levels of displayed shooting data, including an image-only setting that hides all information overlay. Two focusing aids are available: peaking, which highlights the edges of in-focus areas; and magnifying, which provides a 2x enlargement of the central portion of the screen. With the Zebra Pattern Dispaly, high-brightness portions of the image are displayed as a black-and-white zebra pattern. The sensitivity level can be adjusted from 70 to 100 IRE in 5 IRE-unit increments. The 16:9 color viewfinders include aspect guides for industry-standard picture formats, including 4:3, 13:9, 14:9, 1.66:1, 1.75:1, 1.85:1, and 2.35:1. Also, 80 and 90 percent picture and title safe areas can be superimposed. Other available overlays include a center crosshair mark, horizontal level marker, and grid.

Total image control

By giving you total control over more than 23 independently adjustable variables, the XHA1S enables the capture of the perfect look in HD. You can select automatic gain control or one of 3 preset gains (low, medium, or high), which can be assigned values from -3 dB to +36 dB. Numerous white balance modes are provided to ensure color accuracy in a variety of shooting situations. The automatic modes use a high-precision 128-segment through-the-lens metering system. You can also customize white balance settings. Four Knee settings (Auto, High, Middle, Low) provide a choice of dynamic range (knee point) adjustment in the highlight areas to control overexposure when shooting high-brightness subjects. The High setting enables high-key shooting, while the Low setting provides maximum protection from overexposure. There's Gamma control, Master Pedestal, Setup Level, Sharpness adjustment, Horizontal Detail Frequency and a variety of noise reduction settings to accommodate numerous shooting situations and desired image qualities. As if that's not already a load of customization functions, there's also Color Matrix to adjust the color during the shooting, making the footage resemble film or even for images being transferred to film. There's adjustable Color Gain/Phase, and Master Red, Blue, and Green Gain settings, each independently adjustable. Six Color Matrixes, each adjustable from -50 to +50, provide even finer color control capability by altering two of the three primaries. With the XHA1S, you can create your own customized masterpiece.

Image enhancement and program AE

The XHA1S provides advanced features that improve image viewability and maximize visual appeal. Skin Detail mode minimizes imperfections, such as blemishes and wrinkles, without removing detail in other areas of the image. Three intensity levels are provided, and an alternating zebra pattern in the viewfinder simplifies the process of selecting the desired area for the effect. Sky Detail can be used to enhance outdoor footage by removing unwanted detail and noise in the sky. Clear Scan eliminates the flicker and black bands that usually result when shooting a computer or other CRT screen. Frequency is adjustable from 50.2 Hz to 200.3 Hz to accommodate a wide variety of monitors. To help capture images, there are seven programmed Auto Exposure modes to simplify the selection of camera settings for a variety of everyday and special shooting situations. There's Easy Recording and Auto, along with Shutter Priority, Aperture Priority and Manual. Spotlight automatically adjusts exposure for optimum results when the subject is illuminated by a concentrated light source, and Night uses a slower shutter speed to enable capture as ambient light levels begin to fall.

Small in size, large on customization functions

The XHA1S has a lightweight, compact design that employs an internal battery compartment. Size, therefore is not materially affected by the battery used. The compartment will house any BP-900 series battery or DC coupler. The reduced size and weight make the XHA1S easily transportable and maneuverable -- major advantages for location work and specialized "tight-space" shooting, often making it possible to capture footage not possible with larger cameras. The unmatched customization capability built into the XHA1S makes it exceptionally versatile and flexible. The customization features enables the XHA1S to be precision-tailored for different environments, different users, and different jobs. In all, there are 23 image adjustment, 22 display option, and 21 custom function settings that define the camera's performance and operating characteristics. Groups of these settings can be saved and exported to other XHA1S camcorders using an SD memory card or Canon's Console software (included) Up to 9 sets of customized image adjustments can be stroed in the camera's internal memory for instant recall. In addition, two Custom Keys can be programmed to provide instant access to a number of shooting functions to suit the user or the particular application.

Great still photography, too

In addition to the capture and recording of motion video, the XHA1S can also capture digital still images and store them on a memory card. Still images can be captured at full HD (1920 x 1080) resolution in either video color space or digital camera color space. Still images captured in video color space include time code and camera set-up metadata. Still images captured in digital still color space includes EXiF metadata. Also included are numerous advanced still camera features expected from Canon, such as auto exposure bracketing, selectable metering modes, continuous shooting and the option to use select EOS System Speedlight flashes. With many pre/post production, storyboarding, and continuity applications, still image recording is just another way the XHA1S delivers versatility. The memory card slot on the XHA1S accepts SDHC, SD, and MultiMediaCards (MMC). In addition to storing digital still images taken with the camcorder, memory cards also enable camera-to-camera transfer of custom settings. The accessory shoe on the XHA1S can be used to mount optional accessories. The shoe is compatible with E-TTL II Canan Speedlight flashes (for still photography), such as the EX-series models.

Included with purchase

XHA1S with lens cap, lens hood, compact power adapter, component video cable, stereo video cable, USB cable, wireless controller, shoulder strap, battery pack (BP-950G), SD memory card (16 MB), HDVM-E63PR digital video cassette, eyecup, external microphone holder adjustment band, tripod adapter base.

Comparison Specifications

• 20x HD L-series zoom lens, f=4.5-90mm, f/1.6-3.5, Fluorite and UD (Ultra-Low Dispersion) glass elements
• 1/3 in. CCD x 3 (horizontal picture shift), approx. 1,670,000 pixels (1440 x 1080)
• 2.8 in. wide, 16:9 aspect ratio TFT color LCD screen, approx. 207,000 pixels
• HD/DV special 6-pin connector (IEEE 1394 compatible, both input / output), two XLR MIC/LINE inputs, EVF monitor output terminal, component input/output
• Super-range optical image stabilization
• 7 program AE modes: Easy Recording, Auto, Shutter/Aperture Priority, Manual, Spotlight, Night
• Total image control: more than 23 independently adjustable variables
• Minimum illumination: 0.4 lx (60i/24F mode, manual mode, 1/4 shutter, F1.6, gain 18 dB), PAL: 0.3 lux (shutter speed 1/3, when 60i/50i is selected)

Additional Specifications

• DIGIC DV II HD image processor
• Comprehensive focus and zoom control
• True HD 1080 capture with choice of frame rates
• Built-in neutral density filters
• Instant AF, TTL autofocus, manual focusing with focus ring
• Shutter speeds: 1/3 to 1/15,000 second, 1/48 second setting in 24F mode
• Audio: individual level controls, switchable 20 dB mic attenuation, 12 dB mic gain boost, various monitoring options
• Image enhancement: skin detail, sky detail, clear scan
• Unique customization features: 23 image adjustment, 22 display option, 21 custom function settings
• Custom presets: up to 9 sets of customized image adjustments, two custom keys

Manufacturer Specifications

• Canon console software included
• Compact and lightweight with internal battery compartment
• Two built-in digital still cameras: video color space or digital camera color space
• Still image sizes: 1920 x 1080, 1440 x 1080, 848 x 480, 640 x 480 pixels
• Memory card slot accepts SDHC, SD and MultiMediaCard (MMC)
• Flash accessory shoe
• Zebra pattern display, frame overlays, 4:3 output capability
• White balance: auto, pre-set (indoor, outdoor), custom, color temperature setting
• Microphone: stereo electric condenser microphone, 3.5mm stereo mic-jack, audio in terminals (XLR 3-pin jack, 2 systems)
• Tape format: videocassettes bearing the "HDV" or "miniDV" mark

Dimensional Specifications

• Dimensions: 6.4" W x 7.6" H x 15.5" L (excluding lens hood and eyecup)
• Weight (body only): 4.7 lbs. / fully loaded: 5.3 lbs

Canon XH-A1S Warranty Details

One-Year Parts and Labor
