Power up your zone audio

You take the term "home audio system" literally. Music shouldn't be limited to the living room, where most of your A/V components dwell. No, audio should be spread across the home. That's why you've integrated multi-zone audio into your home system. You have stereo speaker pairs throughout the house — in the kitchen, the hallway, the bedroom, in the backyard . . . even in the garage. Wherever you go, you have the ability to enjoy all your favorite tunes. And fueling your whole-home, multi-zone audio experience is the C4630 SE home-audio system, from Sonance. The C4630 SE combines four-source input with six-zone, stereo, 30W-per-channel output, giving you the ability to distribute music from up to four different sources to up to six different stereo speaker pairs located throughout your home. Toss in a CD, queue up your satellite radio subscription, plug in your MP3 player, or set the needle on an LP and listen to any of those sources in six different rooms. And on top of it all, integrated BBE Sound Enhancement technology improves the presence and detail of music, especially at lower listening volumes.

Complete control

When you combine the C4630 SE's six keypad connectors, six zone-specific IR outputs, and RS-232 serial control with Sonance Numeric Keypad Controllers, iPort Music Systems, and IR receivers (all sold separately), you achieve a wide-ranging level of system control. With keypads located in each of the powered stereo zones, or the optional IR remote in hand, you can command your audio experience from wherever you're listening. Further, the included Sonance Control Manager programming software allows a professional programmer to create easy, logical control of the sound in each room and of the system's audio sources, going so far as to set up macro controls to accomplish complex, multi-step operations with the push of a single button.

When six zones just aren't enough

Whether you're taking multi-zone home audio to the extreme or outfitting an office or business with multi-zone audio, sometimes six zones just don't make the cut. Link up to four C4630 SE units together to create an audio system with as many as 24 zones!

Clean-up in Aisle Four

Expanding the functionality of your home audio system, the Sonance C4630 SE features a Paging function. This function allows your system to be overridden by an intercom, telephone system, or microphone preamp output. This feature is ideally suited to professional applications, facilitating communication.

Comparison Specifications

• Output power: 30W RMS x 12 channels @ 8 ohms (6 stereo zones)
• Frequency response: 20Hz - 20kHz±3dB
• Source inputs: 4 x stereo RCA connectors
• Source loop outputs: 4 x stereo RCA connectors
• Zone line outputs: 6 x stereo RCA connectors
• Speaker outputs: 6 x removable 4-pin screw connectors
• Paging connections: 1 x Mono RCA (input) / 1 x Mono RCA (output)
• Computer connection: 1 x USB
• Audio enhancement: BBE Sound Enhancement with individual On/Off controls for each of 4 source inputs
• Control: Sonance Control Manager software included

Additional Specifications

• Extensive macro capability
• Upgradeable firmware
• Keypad control connections: 6 x RJ45 connectors (keypads sold separately)
• IR outputs (Mono 3.5mm connectors: 6 x zone-specific / 4 x programmable / 1 x IR link / 4 x common
• Serial control connection: 1 x RS-232 / Snyc connections: 2 x mono 3.5mm connectors
• 12V control connections: 1 x 2-pin screw connector (input) / 1 x 2-pin screw connector (output) / 14AWG-compatible
• Total harmonic distortion: <0.05% (1kHz) / 0.1% (20Hz - 20kHz)
• Signal-to-noise ratio: -95dB below rated output ("A" weighted)

Manufacturer Specifications

• Source input sensitivity: 200mv
• Source input impedance: 30k ohms / Source output impedance: 100 ohms (buffered)
• Source input voltage (max): 2.0 VAC RMS
• Zone line-out impedance: 100 ohms
• Zone line-out level (fixed/variable): 1:1 (unity gain) / 0dB - +19dB (all volume settings at maximum)
• Serial protocol (inbound): 19,200 baud, 8, N, 1
• Power requirements: 120VAC, 60Hz
• Power consumption: 960W (max power, 12 channels driven)
• AC convenience outlets: 2 (switched)

Dimensional Specifications

• Dimensions: 16.75" W x 5.38" H x 15.0" D
• Weight: Approximately 33 lbs

Sonance C4630 SE Warranty Details

5-year limited parts and labor warranty
